Catalog number: PKS-10-27-AC200V Features: ● Solenoid valve for general fluids. ● A wide range of models are available in terms of fluid, pressure, and caliber. Specifications: ● Effective cross-sectional area (mm2): 220 ● Connection caliber: Rc1 ● Operation method: Electric ● Power supply (V): AC200 ● Number of ports: 2 ● Fluid used: Steam ● Fluid temperature (℃): 5 to 175 ● Cv value: 12 ● Orifice (mm2): 25 ● Operating pressure difference (MPa): 0 to 0.7 ● Fluid temperature: 5 to 175℃ ● Operating pressure: 0 to 0.7MPa ● Effective cross-sectional area (mm2): 71
