CKD check valve CHV2-8-J 1 piece

Catalog number: CHV2-8-J Features: ●Completely prevents backflow of compressed air and other fluids. ●Wide variety of connection sizes (Rc1/8 to Rc1 1/2 in a series) ●Compact, lightweight, and neat shape. ●Fluororubber and oil-free specifications available as options ●Mounting brackets available as options for CHV2-6, CHV2-8, CHV2-8-J, and CHV2-10 only ●An environmentally friendly product that is easy to separate for recycling. Uses: ● To prevent backflow of compressed air Specifications: ● Effective cross-sectional area (mm2): 28 ● Connection diameter: Rc1/4 ● Total length (mm): 50 ● Operating pressure (MPa): 0.03 to 1.0 ● Fluid used: Compressed air ● Width (mm): 25 ● Fluid temperature (℃): 5 to 60 ● Outer dimensions (φ): 25 ● Fluid used: Compressed air ● Operating pressure: 0.03 to 1MPa ● Fluid temperature: 5 to 60℃ ● Ambient temperature range: 0 to 60℃ (but do not freeze) ● Pressure resistance: 1.5MPa Material/Finish: ● Cover, tube: Aluminum alloy ● Valve body, O-ring: Nitrile rubber
