CKD 4K Series Pilot Type 5-Port Select Valve 4KA410-10-DC24V 1 Unit

Catalog number: 4KA410-10-DC24V Features: ● Single solenoid type 5-port valve. ● Direct piping. ● Improved wear resistance and sliding performance of the sliding parts have significantly increased the life span and stabilized responsiveness. Applications: ● For driving cylinders with diameters of Φ125 to Φ160 Specifications: ● Connection diameter: Rc3/8 ● Power supply (V): DC24 ● Fluid used: Compressed air ● Fluid temperature (℃): 5 to 50 ● Sonic conductance (C [dm3/(S・bar)]): 9.8 ● Fluid used: Compressed air ● Operating pressure: 0.15 to 0.7 MPa ● Fluid temperature: 5 to 50℃ ● Wire connection: Grommet lead wire 300 mm Materials/Finish: ● Body: Aluminum die-cast, Spool packing: Nitrile rubber
