CKD 4K Series Pilot Type 5 Port Valve Select Valve 4KB220-06-AC200V 1 Unit

Catalog number: 4KB220-06-AC200V Features: ●Double solenoid type 5-port valve. ●Subplate piping. ●Improved wear resistance and sliding performance of the sliding parts have resulted in a significant increase in lifespan and stable responsiveness. Applications: ●For driving cylinders of Φ40 to Φ80 Specifications: ●Effective cross-sectional area (mm2): 13.5 ●Connection port size: Rc1/8 ●Operation method: Pilot-operated soft spool valve ●Power supply (V): AC200 ●Number of ports: 5 ●Operating pressure (MPa): 0.1 to 0.7 ●Operating fluid: Compressed air ●Fluid temperature (℃): 5 to 50 ●Sonic conductance (C [dm3/(S・bar)]): 2.7 ●Wire connection: Grommet lead wire 300 mm Materials/Finish: ●Body: Aluminum die-cast, Spool packing: Nitrile rubber
