CKD 4K Series Pilot Type 5 Port Valve Select Valve 4KB420-15-AC200V 1 Unit
CKD 4K Series Pilot Type 5 Port Valve Select Valve 4KB420-15-AC200V 1 Unit
Regular price
¥20,328
Regular price
Sale price
¥20,328
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: 4KB420-15-AC200V Features: ●Double solenoid type 5-port valve. ●Subplate piping. ●Improved wear resistance and sliding performance of the sliding parts have significantly increased the life span and stabilized responsiveness. Applications: ●For driving cylinders with diameters of Φ125 to Φ160 Specifications: ●Effective cross-sectional area (mm2): 60 ●Connection port size: Rc1/2 ●Operation method: Pilot-operated soft spool valve ●Power supply (V): AC200 ●Number of ports: 5 ●Operating pressure (MPa): 0.1 to 0.7 ●Operating fluid: Compressed air ●Fluid temperature (℃): 5 to 50 ●Sonic conductance (C [dm3/(S・bar)]): 12 ●Wire connection (mm): Grommet lead wire 300 Materials/Finish: ●Body: Aluminum die-cast, Spool packing: Nitrile rubber
