CKD FRL unit F.R.L combination white series connection size Rc1 C6500-25-WF 1 S

Catalog number: C6500-25-WF Features: ●Space-saving type that integrates a filter, regulator, and lubricator. ●The pressure gauge is embedded in the body, giving it a sleek design while ensuring safety. ●In the event of partial damage, it can be fixed by simply replacing the affected part. ●The element used has a unique chemical fiber structure that has a rough surface and becomes finer toward the inside. It greatly reduces clogging and significantly increases the element lifespan. Uses: * Pressure regulation and quality control of compressed air Specifications: * Filtration accuracy (μm): 5 * Operating pressure (MPa): 1 * Processed air flow rate (m3/min): 5.0 * Connection diameter: Rc1 * Oil storage capacity (cm3): 170 * Overall length (mm): 293 * Overall width (mm): 350 * Set pressure (MPa): 0.05-0.85 * Drain discharge method: Auto drain * Fluid used: Air * Fluid temperature (℃): 5-60 * Drain discharge method: Auto drain * Oil used: Turbine oil type 1 (equivalent to ISO VG#32) * Pressure gauge and bracket included Note: * For the C2500-8000-WF series, the minimum operating pressure of the auto drain is 0.1MPa. Air is purged along with the initial drain until it rises by 0.1MPa.
