DC SWISS Spiral Tap SA450-3 UNF(J)7/16-20 152302 1 piece

Catalog number: 152302 Features: ●Tap tool manufactured for nickel alloys. ●Complies with ISO3161 standards except for the lack of rounding at the bottom of the valley, making it ideal for the aviation industry. Applications: ●For blind hole machining. ●Workpiece material: Nickel alloy. (＞850≦1600 N/m［［M2］］) ●For the aviation industry. Specifications: ●Precision: 3B ●Nominal size: 7/16 ●Pitch (mm): 1.27 ●Thread length (mm): 22 ●Total length (mm): 100 ●Shank diameter (mm): 8 ●Shank square section (mm): 6.2 ●Pilot hole diameter (mm): 10 ●Number of threads: 20 ●Number of engaging threads: 2.5 threads ●Machined thread: Unified thread ●Non-coated Material/Finish: ●Powdered high speed steel (HSS-E-PM)
