DC SWISS Point Tap H320TC-4 M10 110911 1 piece

Catalogue number: 110911 Features: ●Tap tool manufactured for glass fiber and carbon fiber. ●TiCN coating provides long life and high cutting performance. Applications: ●For through hole machining. ●Work material: FRP, cast iron, high tensile steel. ●For the aviation industry. Specifications: ●Precision: 6H ●Nominal size: M10 ●Pitch (mm): 1.5 ●Thread length (mm): 22 ●Total length (mm): 100 ●Shank diameter (mm): 10 ●Shank square section (mm): 8 ●Pilot hole diameter (mm): 8.5 ●Number of engagement threads: 4 ●Machined thread: Metric thread ●TiCN coating Material/Finish: ●High speed steel (HSS-E)
