DC SWISS Point Tap H320TC-4 M2.5 148603 1 piece

Catalog number: 148603 Features: ●Tap tool manufactured for glass fiber and carbon fiber. ●TiCN coating provides long life and high cutting performance. Applications: ●For through hole machining. ●Work material: FRP, cast iron, high tensile steel. ●For the aviation industry. Specifications: ●Precision: 6H ●Nominal size: M2.5 ●Pitch (mm): 0.45 ●Thread length (mm): 10 ●Total length (mm): 50 ●Shank diameter (mm): 2.8 ●Shank square section (mm): 2.1 ●Pilot hole diameter (mm): 2.05 ●Number of engagement threads: 4 ●Machined thread: Metric thread ●TiCN coating Material/Finish: ●High speed steel (HSS-E)
