Catalog number: CX-07 Features: * Multi-function type that can measure decibels and transistors * Comes with a tilted stand for improved workability * Uses gold-plated test leads * Comes with a circuit protection fuse Specifications: ● Batteries used: 2 AA batteries (built-in for testing) ● DC voltage: 0.1/0.5/2.5/10/50/250/1000V ● AC voltage: 10/50/250/1000V ● DC current: 50μA/2.5mA/25mA/250mA/10A ● Resistance: ×1 (2kΩ)/×10 (20kΩ)/×100 (200kΩ)/×1K (2MΩ)/×10K (20MΩ) ● Diode test ● Other measurement functions: Transistor DC current amplification factor (hFE) measurement, low frequency output measurement, continuity test (buzzer at approximately 20Ω or less) ● Accessories: 1 set of test leads, 2 AA batteries (built-in for testing), 1 9V battery (built-in for testing), instruction manual, built-in fuse (0.5A/250V (Φ5×20mm))
