Catalog number: PA-24 Features: ● Crimping pliers with high-precision dies, suitable for crimping small open barrel terminals and QI terminals. ● Equipped with two types of dies, M-type dies and round dies. ● Since the core wire barrel and the coated wire barrel are crimped separately, more than 170 types of terminals can be crimped with high precision. ● High visibility during crimping prevents crimping failure. ● Compact design that fits in the palm of your hand. ● Equipped with a bolt cutter, the length of the small screw can be adjusted. ● The grip is made of an environmentally friendly elastomer that is highly oil-resistant. ● The design grip fits well in the hand. Applications: ● For crimping small open barrel terminals. ● For crimping QI terminals. ●Harness prototyping and connector repair Specifications: ●Total length (mm): 160 ●Hole for attaching string to prevent dropping: None ●Die width (mm): Round type/φ1.4, φ1.8, M type/1.3, 1.6, 1.9, 2.2 ●For connection terminals Material/Finish: ●Body: High carbon steel ●Grip: Elastomer
