GROZ Coolant Spray Nozzle Coolant Mixer 0-11% CMX/1 1 unit

Catalogue No.: CMX/1 Features: ● Used to mix cutting/metalworking fluids and water in a constant ratio. ● Accurate and uniform mix ratio. ● Compact construction with aluminum body and stainless steel rotor disc valve is precision CNC machined for precise performance. ● Mixer operates on a Venturi mechanism powered by the water supply pressure. ● Comes with a brass ball valve and two ball check valves to prevent backflow. ● Easily adjust mix ratio as needed by simply turning the knob. ● Virtually maintenance-free and easy to operate. ● Saves time and money compared to manual mixing. Specifications: ● Flow rate (L/min): 18.3 ● Nominal size: 1/2 ● Mixing ratio: 0-11% ● Hose length (mm): 1000 ● Suction tube length (mm): 900 ● Water intake: 1/2 female ● Mixing ratio: 0-11% ● Flow rate: 18.3 L/min ● Suction tube outer diameter 12 mm Material/Finish: ● Body: Aluminum ● Parts: Aluminum, stainless steel, brass, acetal, PVC, nitrile rubber, polypropylene
