HIOKI Earth Resistance Tester Wireless Set FT6031-90 FT6031-90 1 unit

Catalog number: FT6031-90 Features: ●A set of the installation resistance meter FT6031-50 and the wireless adapter Z3210. ●Compatible with wireless connection, so you can transfer measured values ​​to a smartphone or tablet. ●Significantly reduce work time. ●Excellent noise resistance. ●No dust or water ingress (protection class IP67). ●One unit covers Class A to Class D earth resistance measurements. ●Wide measurement range from 0Ω to 2000Ω. ●Includes auxiliary earth rod and cord winder. Applications: ●For earth resistance measurements. Specifications: ● Ground resistance (Ω): 2000 ● Earth voltage (V): 30.0 ● Power supply (V): 4 x AA alkaline batteries (LR6) ● Minimum display (MΩ): 0.01 ● Width (mm): 185 ● Height (mm): 111 ● Depth (mm): 44 ● Measurement method: 2-electrode method (compatible with D-type measurement) / 3-electrode method (compatible with A-D-type measurement) ● Measurement range / accuracy: 20Ω (0Ω to 20.00Ω) / ±1.5%rdg ±8 dgt, 200Ω (0Ω to 200.0Ω) / ±1.5%rdg ±4 dgt, 2000Ω (0Ω to 2000Ω) / ±1.5%rdg ±4 dgt ● Earth voltage measurement: 0 to 30.0Vrms ●Accuracy: ±2.3%rdg±8dgt(50Hz/60Hz), ±1.3%rdg±4dgt(DC)●Allowable earth voltage: 25.0Vrms(DC or sine wave)●Dustproof performance: IP6, Waterproof performance: IP5/IP7(EN60529)●Functions: Live wire warning display, Zero adjustment, Continuous measurement mode, Wireless communication (only when Z3210 is installed), Comparator●Number of measurements possible: 500 times (measurement conditions: 3-electrode method, 10Ω measurement at 10 second intervals, Z3210 not installed) Set contents/Accessories:●Auxiliary earth rod (2-piece set)●Measurement cord (black 4 m x 1, yellow 10 m with reel x 1, red 20 m with reel x 1)●Carrying case●Protector●4 AA alkaline batteries●Instruction manual●1 wireless adapter
