HIOKI Voltage Logger LR5042 LR5042 1 unit

Catalog number: LR5042 Features: ● Compact logger that can record sensor output and analog output of equipment. ● Small and lightweight pocket size that does not require much space. ● Two-item display that is easy to understand at a glance. ● Equipped with large capacity internal memory (60,000 data per channel). ● Data can be transferred to a PC without stopping recording. ● Batteries can be replaced while recording (recording continues for about 30 seconds even if the battery is removed). ● The previous recorded data is backed up, so you can rest assured even if you make a mistake. Uses: ● For measuring DC voltage ±5V. Specifications: ● Measurement voltage range: -5V to 5V ● Minimum voltage display: 0.001V ● Power supply (V): 1 AAA alkaline battery (included) ● Width (mm): 79 ● Depth (mm): 28 ● Height (mm): 57 ● Power supply: 1 AAA alkaline battery (included) ● Maximum display: 5000 counts ● Protection rating: IP54 ● Measurement items: Voltage (-5V to 5V) 1ch●Recording method: One-time recording (recording stops when memory is full), endless recording (old data is overwritten when memory is full)●Recording mode: Instantaneous value recording (records instantaneous values ​​at each recording interval), statistical recording (measures at 1 second intervals and records instantaneous/maximum/minimum/average values ​​at each recording interval)●Recording interval: 1/2/5/10/12/20/30 seconds, 1/2/5/10/15/20/30/60 minutes●Recording capacity: Instantaneous recording (60,000 data/1ch), statistical recording (15,000 data/1ch)●Display contents: Measurement value, recording interval, date, time, alarm, battery level, number of recorded data, maximum value, minimum value●Function: Data backup (backs up the previous recorded data) Set contents/accessories:●Connection cable (LR9802) x 1●AA alkaline battery (LR06) (built-in) x 1●Instruction manual x 1, operation guide x 1●Stand x 1 Note: Either the LR5091 or LR5092 is required to collect data recorded with the LR5000s Data Logger and transfer it to a computer.
