HIOKI I0r Leak Tester 3355-00 1 unit

Catalog number: 3355-00 Features: * Equipped with a live line megger function that was not possible with insulation resistance testers. * Capable of measuring leakage current (Io), effective leakage current (Ior), and earth insulation resistance (MΩ). * Capable of measuring 1mA accurately. * Compact design suitable for on-site use. Specifications: Power supply (V): 4 x AA alkaline batteries (LR6) Power supply: 4 x AA alkaline batteries (LR6) 90W x 159H x 45Dmm, 440g (including batteries) Clamp sensor 9800 included Measurement items: Leakage current effective value I rms, leakage current filter value I filt, leakage current fundamental wave value I o, effective leakage current value I or, leakage current fundamental wave phase angle value θ, voltage fundamental wave value V, earth insulation resistance value R, frequency Hz Measurement range: Voltage: AC 500 V (effective measurement range: 90 V to 490 V), current: 20.000 mA/ 200.00mA /2.0000 A/ 5.0000 A (effective measurement range is 1% to 110% of range) Material/Finish: Housing: Resin, plastic Set contents/accessories: ●Clamp-on leak sensor 9800 ●Carrying case ●Voltage cord
