ICOMES 6mm Micro Linear Actuator MUED01 (Miracle Gear) MUED01 1 piece

Catalog number: MUED01 Features: ● Ultra-compact micro linear actuator combining a plastic micro gear reducer and a stepping motor. ● Φ6mm micro linear actuator combining a plastic micro gear reducer and a stepping motor. ● Φ8mm micro linear actuator combining a plastic micro gear reducer and a stepping motor. Applications: ● Micro robot joints, liquid control for micro pumps and pulp, etc. ● For small products such as manipulators (patented). Specifications: ● Outer diameter (mm): 6 ● Length (mm): 24.3 ● Reduction method: Mysterious ● Maximum stroke (mm): 4 ● Rated voltage (V): 5 ● Resolution (μm): 0.24 ● Motor (2-phase stepping motor) Material/Finish: ● Stainless steel, resin Set contents/Accessories: ● Cable ● Circuit board ● Product catalog ● Standard nut Caution: ● Depending on the driving conditions, the motor part may become hot during long periods of continuous operation, which may cause damage to the coil. Please be careful.
