ICOMES 8mm Micro Actuator MUCD01 (Planetary Gear 2k-H) MUCD01 1 piece

Catalog number: MUCD01 Features: ●A small microactuator that combines a plastic micro gear reducer and a stepping motor. Applications: ●For small products such as microrobot joints and micropumps. Specifications: ●Outer diameter (mm): 8 ●Length (mm): 18.8 ●Reduction method: 2K-H ●Reduction ratio: 1/8 ●Rated voltage (V): 5 ●Output torque (mN･m): 2 ●Motor (2-phase stepping motor) ●Number of steps per rotation (160) ●Motor resistance (21Ω) Material/Finish: ●Stainless steel, resin Set contents/Accessories: ●Cable ●Platform ●Product catalog ●Inspection report Caution: ●Depending on the driving conditions, the motor part may become hot during long periods of continuous operation, which may cause damage to the coil. Please be careful.
