ICOMES 8mm Micro Actuator MUI308 (Miracle Gear) MUI308 1 piece

Catalog number: MUI308 Features: ● A small microactuator that combines a plastic micro gear reducer and a stepping motor. Applications: ● For small products such as microrobot joints and micropumps. Specifications: ● Outer diameter (mm): 8 ● Length (mm): 18.8 ● Reduction method: Magic ● Reduction ratio: 1/83.3 ● Rated voltage (V): 5 ● Output torque (mN･m): 6 ● Motor (2-phase stepping motor) ● Number of steps per rotation (1666.7) ● Motor resistance (21Ω) Material/Finish: ● Stainless steel, resin Set contents/Accessories: ● Cable ● Circuit board ● Product catalog Caution: ● Depending on the driving conditions, the motor part may become hot during long periods of continuous operation, which may cause damage to the coil. Please be careful.
