ICOMES 8mm Micro Linear Actuator MUI102 (Planetary Gear 2k-H MUI102 1 pc

Catalog number: MUI102 Features: ● Ultra-compact micro linear actuator combining a plastic micro gear reducer and a stepping motor. ● Φ6mm micro linear actuator combining a plastic micro gear reducer and a stepping motor. ● Φ8mm micro linear actuator combining a plastic micro gear reducer and a stepping motor. Applications: ● Micro robot joints, liquid control for micro pumps and pulp, etc. ● For small products such as manipulators (patented). Specifications: ● Outer diameter (mm): 8 ● Length (mm): 31.5 ● Reduction method: 2K-H ● Maximum stroke (mm): 7 ● Rated voltage (V): 5 ● Resolution (μm): 2.5 ● Motor (2-phase stepping motor) Material/Finish: ● Stainless steel, resin Set contents/Accessories: ● Cable ● Circuit board ● Product catalog ● Standard nut Caution: ● Depending on the driving conditions, the motor part may become hot during long periods of continuous operation, which may cause damage to the coil. Please be careful.
