IS Thread Cutting Dies Metric Threads, Coarse Thread, 25 Diameter, M5X0.8 IS-RD-25-M5X0.8 1 pc

Catalog number: IS-RD-25-M5X0.8 Features: ●A female-threaded tool with a hole to allow chips to escape. ●Comes with an adjustment screw. Applications: ●Machined threads: Metric threads, regular threads ●For machining male threads. ●Workpiece material: Low carbon steel Specifications: ●Nominal size: M5 ●Pitch (mm): 0.8 ●Outer diameter (mm): 25 ●Thickness (mm): 9 ●Machined threads: Metric threads Material/Finish: ●Tungsten steel (SKS2) Caution: ●Cannot be used with stainless steel screws.
