IS Long Shank Jet Tap L=150 M22X2.5 L150JET-M22X2.5 1 piece

Catalog number: L150JET-M22X2.5 Features: ● The groove is shallow and the core is thick, so it is less likely to break. ● It has been homogenized. ● The shank is longer than normal products, so it is used when the machining position is deep. Applications: ● For through hole machining. ● Work material: general steel, low-medium carbon steel, alloy steel. Specifications: ● Precision: H4 ● Nominal size: M22 ● Pitch (mm): 2.5 ● Thread length (mm): 38 ● Total length (mm): 150 ● Shank diameter (mm): 17 ● Shank square section (mm): 13 ● Pilot hole diameter (mm): 19.5 ● Number of engagement threads: 5 threads ● Machining thread: Metric thread ● Surface treatment: Homogeneous treatment Material/Finish: ● High speed steel (HSS-E)
