JST VH connector base pin top type (100 pieces) B10P-VH 1 bag

Catalog number: B10P-VH Features: ●Enables a wide range of connections from signal circuits in electronic devices to power circuits and output circuits. Applications: ●For wiring inside devices. ●3.96mm pitch for wire-to-board connections. Specifications: ●Number of poles: 10 ●Compatible wire range: AWG #22 to #18 ●Shape: Top type ●Withstand voltage (V): AC1500/1 minute ●Rated current: 7A ●A (mm): 35.64 ●B (mm): 39.54 ●Insulation resistance: 1000MΩ or more ●Rated voltage (V): 250V ●Operating temperature range: -25℃ to +85℃ (including temperature rise value) Material/Finish: ●Brass, copper-undercoated, tin-plated (reflow treatment) ●Base: Nylon 66 (UL94V-0)
