JUBILEE Hose Clip, Clamping Diameter 158-190mm (5 Pieces) JBL-7.5SS316 1 Bag

Catalog number: JBL-7.5SS316 Features: ● Made of all stainless steel (SUS316), suitable for use in coastal areas. ● The slits in the band are non-penetrating, so the hose is less likely to be damaged. ● Slits are applied to the entire band, allowing fine adjustment of the band tightening. ● The ends of the hose band are also neatly deburred, making the hose less likely to be damaged. ● It is less likely to loosen even with vibration or impact. ● It can be tightened with either a hexagonal (7.0 mm) or flathead screwdriver. Applications: ● For use on ships, bridges, harbors, and coastal areas of the food industry. ● For agricultural machinery, heavy machinery, and machine tools. ● For fastening pneumatic and hydraulic piping and construction equipment. ● For sites where rust is unacceptable. Specifications: ● Maximum diameter (mm): 190 ● Minimum diameter (mm): 158 ● Band width (mm): 13 ● Thickness (mm): 0.914 ● Tightening torque (N・m): 5.9-7.9 ● Hexagonal bolt (mm): 7.0 ● Tightening: Hexagonal (7.0mm), flathead screwdriver ● Lloyd's Register certified, BS: 5315/DIN3017 standard certified, SAE J1508 (Type FE), salt spray test (NSS): 2000 hours Material/Finish: ● Stainless steel (SUS316)
