KDS Super Ray 96 ATL-96 1 unit

Catalog number: ATL-96 Features: ● Ultra-high brightness type that is easy to see even in bright places. ● Equipped with a fixed line mode that allows the laser to be emitted even when tilted. ● 3-way power source that can use lithium-ion rechargeable batteries, alkaline batteries, or AC power. ● Comes with one-year theft and fire compensation. Applications: ● For setting and checking horizontal and vertical standards. ● For positioning partitions. ● For installing machines, etc. Specifications: ● Height (mm): 206 ● Width (mm): 122 ● Precision: ±1mm/10m ● Automatic correction range: ±2.5° ● Power supply: Lithium-ion rechargeable battery, 4 AA alkaline batteries or rechargeable batteries, AC adapter ● Protection rating: IP54 ● Irradiation line: Vertical: 4 directions, Horizontal: 360° ● Light source: Visible light semiconductor laser ● Light output (mW): 1 or less ● Wavelength (nm): Line: 635, Marking point: 650 ● Laser safety standard: Class 2 (JIS C6802:2014) ● Braking method: Magnetic braking method ● Line width (mm): Approximately 2/5m ● Right angle accuracy: 90° ±0.012° ● Color: White ● Width (mm): 122 ● Depth (mm): 115 ● Height (mm): 206 ● Tripod mounting part: 5/8 inch ● Operating temperature range (℃): -10℃ to +40℃ ● Battery life: Dry battery: Approximately 4 hours, Rechargeable battery: Approximately 7 hours ● Power source (V): Lithium-ion rechargeable battery/Alkaline dry battery, AC power source ● Vertical 4-direction square, horizontal all-around, ground mark ● Compatible receiver: LRV-4 ● Compatible tripod: LEC4M Material/Finish: ● Body cover: ABS resin ● Base: Aluminum Set contents/Accessories: ● Lithium-ion rechargeable battery ● Alkaline dry batteries x 4 ● Charger ● Laser goggles Note: ● Receiver and tripod are sold separately.
