KDS Mint Green Laser 401 Unit Only RGL-401 1 Unit

Catalog number: RGL-401 Features: ●Mint green laser type with reduced glare. ●Equipped with a dimming function that allows you to adjust the brightness of the line between 1 and 100%. ●Uses a quick damping system that allows the line to be leveled more quickly than previous models. ●The carrying case is highly durable, equivalent to IP66. ●The remaining battery level is displayed in three stages on the operation panel. ●2-way power supply specification that can be used with batteries or AC power. ●360° full-circle fine adjustment is possible. Applications: ●For positioning partitions, etc. ●For centering through the ceiling. ●For positioning machine installation, etc. Specifications: ● Height (mm): 200 ● Width (mm): 114 ● Precision: ±1mm/7.5m ● Automatic correction range: Approximately ±2° ● Power supply: 4 AA alkaline batteries (Ni-MH rechargeable batteries) or AC adapter ● Protection rating: IP54 ● Irradiation lines: 2 vertical directions, 1 horizontal direction ● Light source: Visible light semiconductor laser ● Light output (mW): 1 or less ● Wavelength (nm): 505 ● Laser safety standard: Class 2 (JIS C6802: 2014) ● Braking method: Magnetic braking method ● Line width (mm): Approximately 2 (/5m) ● Right angle accuracy: 90° ± 0.017° ● Color: Blue ● Width (mm): 114 ● Depth (mm): 111 ● Height (mm): 200 ● Tripod mounting part: 5/8 inch ● Operating temperature range (℃): -10℃ to +40℃ ● Battery life: Approximately 4 hours (when all lights are on) ● 2 vertical directions, 1 horizontal direction, ground mark Material / Finish: ● Main body cover: ABS resin ● Base: Aluminum Set contents / Accessories: ● Laser level main body ● Carrying case (with belt): CASE-12 ● Laser goggles: GLG-1 ● AA nickel metal hydride rechargeable battery: RB-4N ● Charger QC-650 ● L-shaped target board x 2 (red) ● AA alkaline battery x 4 (for trial use) ● Instruction manual ● User registration card and warranty card Caution: ●Before starting operation, be sure to check the accuracy of the equipment according to the instruction manual. ●Do not look directly into the beam.
