KG Spiral Miter Gear M2.5S 30L-6318H M2.5S 30L-6318H 1 pc

Catalog number: M2.5S 30L-6318H Features: ●H at the end of the part number indicates induction hardening. Applications: ●Used for general industrial machinery, food machinery, medical equipment, etc. Specifications: ●Module: 2.5 ●Number of teeth: 30 ●Pitch circle diameter (mm): φ75 ●Assembly distance (mm): 63 ●Hole diameter (mm): φ18 ●Total length (mm): 37.07 ●Tooth width (mm): 15 ●Tooth tip circle diameter (mm): φ76.2 ●Hub outer diameter (mm): φ55 ●Hub length (mm): 20 ●Twist direction: L ●Hole length (mm): 34.5 ●Tooth ratio: 1 ●Tooth tip angle: 48°3′ ●Gear precision: JIS B 1704 (ISO) Class 3 (Induction hardened product: Class 4) ●Pressure angle: 20° ●Twist angle 35° ●Induction hardening Material/Finish: ●S45C (Carbon steel for mechanical structures) Caution: ●Using the mating gear in combination with a product from another company may cause malfunctions.
