KHK Worm Wheel AG0.5-60R1 AG0.5-60R1 1 piece

Catalog number: AG0.5-60R1 Features: ● Worm wheel made of aluminum bronze with excellent wear resistance. ● Wide variety of products available. Applications: ● Power transmission gears. Specifications: ● Module: 0.5 ● Number of teeth: 60 ● Hole diameter (mm): φ5 ● Tooth shape: Straight teeth ● Shape: HA ● Total length: 12 ● Boss diameter: 25 ● Tooth tip circle diameter: 31 ● Reference circle diameter: 30 ● Tooth width: 5 ● Boss length (right): 7 ● Gear precision: KHK W 002: Class 2 ● Surface treatment: None ● Pressure angle: 20° ● Tooth surface finish: None ● Gear cutting reference surface: Hole (H7) ● Heat treatment: None ● Additional processing possible: Yes Material/Finish: ● CAC702 Note: ● Sold individually, not as a set.
