KHK Worm Wheel AG4-20R1 AG4-20R1 1 piece

Catalog number: AG4-20R1 Features: ● Worm wheel made of aluminum bronze with excellent wear resistance. ● Wide variety of products available. Applications: ● Gears for power transmission. Specifications: ● Module: 4 ● Number of teeth: 20 ● Hole diameter (mm): φ20 ● Tooth shape: Straight teeth ● Shape: H1 ● Overall length: 50 ● Boss diameter: 60 ● Tooth tip circle diameter: 92 ● Reference circle diameter: 80 ● Tooth width: 30 ● Boss length (right): 20 ● Gear precision: KHK W 002: Class 2 ● Surface treatment: None ● Pressure angle: 20° ● Tooth surface finish: None ● Gear cutting reference surface: Hole (H7) ● Heat treatment: None ● Additional processing possible: Yes Material/Finish: ● CAC702 Note: ● Sold individually, not as a set.
