KHK Worm Wheel PG1-20R1 PG1-20R1 1 piece

Catalog number: PG1-20R1 Features: ●Lightweight and strong worm wheel made of MC nylon. ●Can be used without lubrication, making it ideal for food machinery. Applications: ●Power transmission gears. Specifications: ●Module: 1 ●Number of teeth: 20 ●Hole diameter (mm): φ6 ●Tooth profile: Straight teeth ●Shape: H1 ●Total length: 20 ●Boss diameter: 16 ●Tooth tip circle diameter: 23 ●Reference circle diameter: 20.04 ●Tooth width: 10 ●Boss length (right): 10 ●Gear precision: KHK W 002: Grade 5 ●Tooth profile: Straight teeth ●Surface treatment: None ●Pressure angle: 20°/14°30′ ●Tooth surface finish: None ●Gear cutting reference surface: Hole ●Heat treatment: None ●Additional machining possible: Yes Material/Finish: ●MC901 Note: ●Sold individually, not as a set.
