KHK Worm Wheel PG1.5-20R2 PG1.5-20R2 1 piece

Catalog number: PG1.5-20R2 Features: ●Lightweight and strong worm wheel made of MC nylon. ●Can be used without lubrication, making it ideal for food machinery. Applications: ●Power transmission gears. Specifications: ●Module: 1.5 ●Number of teeth: 20 ●Hole diameter (mm): φ8 ●Tooth shape: Straight teeth ●Shape: H1 ●Total length: 22 ●Boss diameter: 22 ●Tooth tip circle diameter: 34.5 ●Reference circle diameter: 30.22 ●Tooth width: 12 ●Boss length (right): 10 ●Gear precision: KHK W 002: Grade 5 ●Surface treatment: None ●Pressure angle: 20° ●Tooth surface finish: None ●Gear cutting reference surface: Hole ●Heat treatment: None ●Additional machining possible: Yes Material/Finish: ●MC901 Note: ●Sold individually, not as a set.
