KHK Stainless Steel Worm SUW1.5-R1 SUW1.5-R1 1 pc

Catalog number: SUW1.5-R1 Features: * Rust-resistant stainless steel worm. * Best used in combination with DG and PG wheels. Applications: * Power transmission gears. Specifications: ●Module: 1.5 ●Hole diameter (mm): φ8 ●Tooth form: Straight tooth ●Shape: W1 ●Tooth width (mm): 30 ●Number of grooves: 1 ●Total length (mm): 40 ●Boss diameter (mm): φ20 ●Lead angle: 3°26′ ●Tooth tip circle diameter: φ28 ●Hole length: 28 ●Tooth width b (mm): 30 ●Reference circle diameter d (mm): 25 ●Twist direction: R ●Worm twist direction and number of grooves (mm): R 1 ●Gear precision: KHK W 001: Grade 4 ●Tooth surface hardness: (187HB or less) ●Surface treatment: None ●Pressure angle: 20° ●Tooth surface finish: None ●Gear cutting reference surface: Hole (H7) ●Heat treatment: None ●Additional processing possible: Yes Material/Finish: ●SUS303 Note: ●Sold individually, not as a set.
