KHK Stainless Steel Worm SUW2-R2 SUW2-R2 1 piece

Catalog number: SUW2-R2 Features: * Rust-resistant stainless steel worm. * Best used in combination with DG and PG wheels. Applications: * Power transmission gears. Specifications: ●Module: 2 ●Hole diameter (mm): φ12 ●Tooth form: Straight tooth ●Shape: W1 ●Tooth width (mm): 32 ●Number of grooves: 2 ●Total length (mm): 46 ●Boss diameter (mm): φ25 ●Lead angle: 7°25′ ●Tooth tip circle diameter: φ35 ●Hole length: 35 ●Twist direction: R ●Worm twist direction and number of grooves (mm): R 2 ●Reference circle diameter d (mm): 31 ●Tooth width b (mm): 32 ●Gear precision: KHK W 001: Grade 4 ●Tooth surface hardness: (187HB or less) ●Surface treatment: None ●Pressure angle: 20° ●Tooth surface finish: None ●Gear cutting reference surface: Hole (H7) ●Heat treatment: None ●Additional processing possible: Yes Material/Finish: ●SUS303 Note: ●Sold as a single piece, not a set.
