KHK Stainless Steel Worm SUW0.5-R2 Straight Teeth SUW0.5-R2 1 pc

Catalog number: SUW0.5-R2 Features: * Rust-resistant stainless steel worm. * Best used in combination with a PG wheel. Applications: * Power transmission gears. Specifications: ●Module: 0.5 ●Hole diameter (mm): φ5 ●Tooth form: Straight teeth ●Shape: W2 ●Pitch diameter (mm): φ11 ●Tooth width (mm): 10 ●Number of grooves: 2 ●Tooth tip diameter (mm): φ12 ●Total length (mm): 18 ●Lead angle: 5°13′ ●Hole length (mm): 12 ●Tap: M3 ●Worm twist direction and number of grooves (mm): R2 ●Mounting screw S: 3 ●Mounting screw M: M3 ●Twist direction: R ●Gear precision: KHK W 001: Grade 4 ●Tooth hardness: (187HB or less) ●Surface treatment: None ●Pressure angle: 20° ●Tooth finish: None ●Gear cutting reference surface: Hole (H7) ●Heat treatment: None ●Can additional processing be done: Yes Material/Finish: ●SUS303 Note: ●This is sold as a single piece, not a set.
