KHK Round Rack SRO3-500 SRO3-500 1 pc

Catalogue number: SRO3-500 Features: ● Useful for reciprocating the rack side. Applications: ● Power transmission gears. Specifications: ● Module: 3 ● Overall length (mm): 505 ● Effective number of teeth: 52 ● Mesh height h” (mm): 27 ● Tooth width b (mm): 30 ● Outside diameter (mm): 30 ● Shape: R2 ● Mesh height (mm): 27 ● Outside diameter: 30 ● Gear precision: KHKR001: Grade 4 ● Tooth shape: Straight teeth ● Pressure angle: 20° ● Heat treatment: None ● Tooth surface hardness: (95HRB or less) ● Surface treatment: Blackening ● Tooth surface finish: Cutting ● Additional processing possible: Yes Material/Finish: ● S45C Note: ● Sold individually, not as a set.
