KHK Geared Worm SWG4-R1 SWG4-R1 1 pc

Catalog number: SWG4-R1 Features: ● Reasonably priced ground worm. ● Tooth surface is induction hardened. Applications: ● Power transmission gears. Specifications: ●Twist right/left: R ●Module: 4 ●Number of threads: 1 ●Pitch circle diameter (mm): 62 ●Hole diameter (mm): 22 ●Shape: W3 ●Total length: 100 ●Boss diameter: 50 ●Tooth tip circle diameter: 70 ●Tooth width: 70 ●Lead angle: 3°41′ ●Boss length (right): 25 ●Boss length (left): 5 ●Gear precision: KHKW001: Class 2 ●Tooth form: Straight teeth ●Pressure angle: 20° ●Heat treatment: High-frequency hardening of tooth surface ●Tooth surface hardness: 50-60HRC ●Surface treatment: Blackening except for ground parts ●Tooth surface finish: Grinding ●Gear cutting reference surface: Hole (H7) ●Can additional processing be done: Yes Material/Finish: ●S45C Note: ●Sold as a single piece, not a set.
