KHK Gear Spur SSG2-56J32 SSG2-56J32 1 pc

Catalog number: SSG2-56J32 Features: ● The teeth are hardened, but additional processing is possible. Applications: ● Power transmission gears. Specifications: ●Module: 2 ●Number of teeth: 56 ●Shape: S1K ●Pitch circle diameter (mm): 112 ●Tooth width (mm): 20 ●Hole diameter (mm): 32 ●Tooth tip circle diameter: 116 ●Total length (mm): 36 ●Boss diameter (mm): 60 ●Boss length (mm): 16 ●Tap: M8 ●Key groove: 10 x 3.3 ●Screw hole position: 8 ●Gear precision: Equivalent to JIS B 1702-1 N7 grade ●Tooth surface hardness: 50 to 60 HRC ●Tooth shape: Straight teeth ●Surface treatment: Blackening except for teeth (Additional processing parts are not re-blackened.) ●Pressure angle: 20° ●Tooth surface finish: Grinding ●Gear cutting reference surface: Hole (H7) ●Heat treatment: High-frequency hardening of tooth surface Material/Finish: ●S45C Note: ●This product is a contracted product and will be completed by the manufacturer within 3 days of ordering. (Logistics is not included) *This product cannot be cancelled as it will be processed immediately after ordering. *This is a single item, not a set.
