Catalog number: BSU10 Features: ● A spring is built into the screw body, and the ball is stroked and positioned by pressure. Applications: ● Positioning parts such as indexing and stoppers. Specifications: ● Load (N): 20.0 to 35.0 ● Screw dimensions: M10 x 1.50 ● Stroke (mm): 2.0 ● Total length (mm): 19 ● Pole diameter (mm): 6 ● Heat resistance temperature: 180°C Materials/Finish: ● Body: Stainless steel (SUS303) ● Ball: Stainless steel (SUS420)
