Catalog number: BSU12 Features: ● A spring is built into the screw body, and the ball is stroked and positioned by pressure. Applications: ● Positioning parts such as indexing and stoppers. Specifications: ● Load (N): 30.0 to 55.0 ● Screw dimensions: M12 x 1.75 ● Stroke (mm): 2.5 ● Total length (mm): 22 ● Pole diameter (mm): 8 ● Heat resistance temperature: 180°C Materials/Finish: ● Body: Stainless steel (SUS303) ● Ball: Stainless steel (SUS420)
