Catalog number: BSU3 Features: ● A spring is built into the screw body, and the ball is stroked and positioned by pressure. Applications: ● Positioning parts such as indexing and stoppers. Specifications: ● Load (N): 1.5 to 3.0 ● Screw dimensions: M3 x 0.50 ● Stroke (mm): 0.5 ● Total length (mm): 7 ● Pole diameter (mm): 1.5 ● Heat resistance temperature (℃): 180 Materials/Finish: ● Body: Stainless steel (SUS303) ● Ball: Stainless steel (SUS420)
