Catalog number: BSU5 Features: ● A spring is built into the screw body, and the ball is stroked and positioned by pressure. Applications: ● Positioning parts such as indexing and stoppers. Specifications: ● Load (N): 6.0 to 11.0 ● Screw dimensions: M5 x 0.80 ● Stroke (mm): 0.9 ● Total length (mm): 12 ● Pole diameter (mm): 3 ● Heat resistance temperature: 180°C Materials/Finish: ● Body: Stainless steel (SUS303) ● Ball: Stainless steel (SUS420)
