Catalog number: BSU8 Features: ● A spring is built into the screw body, and the ball is stroked and positioned by pressure. Applications: ● Positioning parts such as indexing and stoppers. Specifications: ● Load (N): 15.0 to 30.0 ● Screw dimensions: M8 x 1.25 ● Stroke (mm): 1.5 ● Total length (mm): 16 ● Pole diameter (mm): 5 ● Heat resistance temperature: 180°C Materials/Finish: ● Body: Stainless steel (SUS303) ● Ball: Stainless steel (SUS420)
