Catalog number: ED16ST Features: ● Small capacity type that combines power and speed. ● Equipped with mechanical brake. ● Equipped with upper limit switch and overwinding prevention device. ● Uses a strong load chain (hardened alloy steel chain with special rust prevention treatment). Applications: ● High speed winding and lowering greatly improves work efficiency. ● By using low speed, it is effective for precision work such as alignment and mold matching. Specifications: ● Rated load (t): 0.16 ● Standard lifting height (m): 3 ● Winding speed (m/min) low speed: 4 ● Winding speed (m/min) high speed: 20 ● Minimum distance between hooks (mm): 330 ● Time rating (min): 25 ● Power supply (V): Single phase 100V ● Power cord length (m): 5m (with 3P plug) ● Power supply: Single phase 100V ● Motor output (kW): 0.6 ● Power cord: 5m (with 3P plug) ● 2-speed type ● Operating voltage: 100V ● 2-point push button type Material/Finish: ● Load chain: Nickel-plated special alloy steel
