Catalog number: ED10SD Features: ● Small capacity type that combines power and speed. ● Equipped with mechanical brake. ● Equipped with upper limit switch and overwinding prevention device. ● Can be adjusted to the optimum speed according to the work. ● Uses a strong load chain (hardened alloy steel chain with special rust prevention treatment). Specifications: ● Rated load (t): 0.10 ● Standard lifting height (m): 3 ● Winding speed (m/min) low speed: 1.5 to 9.0 ● Winding speed (m/min) high speed: 1.5 to 15.0 ● Minimum distance between hooks (mm): 315 ● Time rating (min): 15 ● Power supply (V): Single phase 100V ● Power cord length (m): 5m (with 3P plug) ● Power supply: Single phase 100V ● Motor output (W): 300 ● Power cord: 5m (with 3P plug) ● 2-speed selection type ● Operating voltage: 100V ● 2-point push button type Material/Finish: ● Load chain: Nickel-plated chain
