KOGI Air Amplifier Nozzle Transvector Stainless Steel 902XSS Nozzle Diameter φ30 902XSS 1 pc

Catalog number: 902XSS Features: ● Attracts and sucks in the surrounding air, allowing for a large volume of air to be blown. ● Can blow 2 to 20 times the volume of air depending on the model. ● Wide-angle nozzle (full angle 15°) is good for blowing over a wide area. ● Adjustment is possible using the scale. Applications: ●Blow: chips, cleaning, smoke, draining ●Suction: chip collection, hole cleaning, exhaust, smoke exhaust ●Transport: foam material, paper waste, food materials, medicines, powder ●Draining: various rod shapes (passes through the inner diameter) ●Suction + blow: chemical spray Specifications: ●Nozzle mounting port: NPT-1/4 ●Nozzle aperture (mm): φ30 ●Total length (mm): 74.7 ●Operating air pressure (MPa): 0.29 to 0.69 ●Air consumption (NL/min): 240 to 482 (at slit width 0.05 mm) ●Outer diameter (mm): Maximum Φ48.3 ●Minimum aperture (mm): φ20 ●Maximum operating pressure (MPa): 1 ●Compatible fluid: compressed air (compressor air) Material/Finish: ●Stainless steel Caution: ●Use clean compressed air.
