MAPAL Carbide Roughing End Mill OptiMill-Composite (SCM460) Composite End Mill Blade Diameter 16 x Blade Length 36 x Total Length 92 mm SCM460-1600Z08R-F0020HA-HC611 1 piece

MAPAL Carbide Roughing End Mill OptiMill-Composite (SCM460) Composite End Mill Blade Diameter 16 x Blade Length 36 x Total Length 92 mm SCM460-1600Z08R-F0020HA-HC611 1 piece

JAN： 　
Carbide Roughing End Mill Carbide roughing end mill (for aircraft) Cutting Tools Mapal End Mill Z Turning and milling tools
¥94,348
¥94,348
Sale Sold out
Shipping calculated at checkout.
Catalog number: SCM460-1600Z08R-F0020HA-HC611 Features: ●High-efficiency machining (high feed rate) is achieved with multiple blades for composite materials such as CFRP. ●Chips rise upwards due to the right-hand twist specification. Applications: ●Workpiece: Composite materials such as CFRP. Specifications: ●Blade diameter (mm): 16 ●Blade length (mm): 36 ●Total length (mm): 92 ●Shank diameter (mm): 16 ●Number of blades (pieces): 8 ●Surface treatment: HC619 diamond coating ●Twist angle: Right-hand twist/8° Material/Finish: ●Ultra-fine particle carbide alloy
