MAPAL Carbide Roughing End Mill OptiMill-Composite (SCM470) Composite End Mill Blade Diameter 5 x Blade Length 18 x Total Length 60 mm SCM470-0500Z08R-F0010HA-HC619 1 piece

MAPAL Carbide Roughing End Mill OptiMill-Composite (SCM470) Composite End Mill Blade Diameter 5 x Blade Length 18 x Total Length 60 mm SCM470-0500Z08R-F0010HA-HC619 1 piece

JAN： 　
Carbide Roughing End Mill Carbide roughing end mill (for aircraft) Cutting Tools Mapal End Mill Z Turning and milling tools
¥40,788
¥40,788
Sale Sold out
Shipping calculated at checkout.
Catalog number: SCM470-0500Z08R-F0010HA-HC619 Features: ●High-efficiency machining (high feed rate) is achieved by using multiple blades for composite materials such as CFRP. ●Chips fall downwards due to the left twist specification. Applications: ●Workpiece: Composite materials such as CFRP. Specifications: ●Blade diameter (mm): 5 ●Blade length (mm): 18 ●Total length (mm): 60 ●Shank diameter (mm): 6 ●Number of blades (pieces): 8 ●Surface treatment: HC619 diamond coating ●Twist angle: Left twist/8° Material/Finish: ●Ultra-fine particle carbide alloy
