Catalog number: MRA-ERC25.1500 Features: ●High-precision AA class (UP class) collet with core runout accuracy of within 5 μm. ●Collet sizes are available in six types: ER8, ER11, ER16, ER20, ER25, and ER32. Applications: ●For drilling, end milling, and reaming. Specifications: ●Gripping diameter (mm): 14.0-15.0 ●Outer diameter (mm): 26 ●Total length (mm): 34 ●Standard: ER25 ●4d tip runout accuracy: 5 μm ●European standard 16° taper collet (= one angle 8°) ●DIN6499 ●ISO15488
