NKK Union/Nipple Type Flexible Hose Fitting FCMB 15A x 500L NK-1900/FCMB-15A-500L 1 Piece

Catalog number: NK-1900/FCMB-15A-500L Features: ●Easy piping and smooth operation. ●Available for diameters and lengths other than those listed. Applications: ●General piping such as absorbing misalignment. ●Applicable fluids: cold and hot water, steam, oil, gas (non-corrosive fluids only) Specifications: ●Nominal diameter A: 15 ●Nominal diameter B: 1/2 ●Total length (mm): 500 ●Compatible fluids: cold and hot water, oil, air, gas (non-corrosive fluids only) ●Nominal diameter (mm): 21.70 ●Maximum operating pressure: 1MPa ●Operating temperature range: -10 to 100°C ●Connection: Tapered male thread (R) x tapered female thread (Rc) Material/Finish: ●Flexible part: Stainless steel (SUS304) ●Union/Nipple part: Cast iron (FCMB), carbon steel (SS400)
