NICHIDO DC Welding Machine Digital Inverter Welding Machine Three-phase 200V 300A DIGITAL-300A 1 unit

Catalog number: DIGITAL-300A Features: *Compact, lightweight, and powerful. The welding current value is displayed digitally, and the functionality has been improved. *Suitable for working in tight spaces. Applications: *For repair work on steel frame construction, shipbuilding, bridge construction, etc. Specifications: ●Welding rod diameter (mm): 6.0 ●Input voltage (V): Three-phase 200 ●Rated input (kVA): 8.0 ●Output current (A): 300 ●Utilization rate (%): 50 ●Width (mm): 224 ●Depth (mm): 480 ●Height (mm): 290 ●Frequency (Hz): 50/60 ●Primary cable length: 5m ●With electric shock prevention function ●Round terminal at the end of the cable ●200V input side: Round terminal ●Input wire length: 2m ●Capacity (KVA): 15.2 ●Rated capacity (KW): 12.2 ●Rated load voltage (V): 42 ●No-load voltage (V): 24/84 Set contents/accessories: ●Terminal cover x 2 ●Bolt nut set x 2 ●Shoulder belt Note: ●Secondary side cable (earth holder, holder) is sold separately. ●Power input is a crimp terminal, not a plug type. ●Indoor type. Do not use outdoors in rainy weather.
