NKC Coupling NL Type Coupling Socket R1 Male Thread NL-48SM 1 pc

Catalog number: NL-48SM Features: *The automatic open/close valve built into the socket opens and closes according to the insertion and removal of the plug, so there is no need to operate the main valve each time the plug is inserted or removed. *Both sockets and plugs are available for male thread connection, female thread connection, and hose connection, allowing for free combinations. *The mating parts of NL21 to NL24 have the same dimensions and are compatible with each other. *NL44 to NL48 are also similarly compatible. Uses: ● Pneumatic tools, various air piping, pneumatic equipment, drainage pipes, etc. Specifications: ● Pressure resistance (MPa): 2.0 ● Fluid used: Air ● Operating temperature range (℃): -20 to +80 ● Maximum operating pressure (MPa): 1.5 ● Mating mounting size: Rc1 thread ● Compatible coupler: NL40 series type ● Hexagonal side size (mm) H1: 35 ● Width (mm): 69 ● Depth (mm): 35 (Hexagon) ● Hexagonal side size (mm): Hexagonal side size (mm) Material/Finish: ● Body: Steel (nickel chrome plated) Caution: ● Use at or below the maximum specified pressure.
